150110251_view_type_01

150 110 251

ICONES-prod-2
Claw Clip Butterfly®
ICONES-weight
1,2 grs
150110251_view_type_01

Main Features

Technical data

Blind assembly in the window
Function guaranteed up to 6 disassemblies
Installation load on clip support less than 20N with a thickness from 1.50 to 2.00 mm
Average assembly load in ABS (polypropylene) window less than 30N
Average disassembly load to be defined according to environment and material

Characteristics

Material

Treatments

Clip

Steel XC68

Quenched and tempered

Grey Delta Protekt KL100

Other treatments avalaible on request

Dimensions

Data_Sheet_150110
[ units in inch ]
150093251_view_type_02

150 093 251

ICONES-prod-2
Claw Clip Butterfly®
ICONES-weight
0,9 grs
150093251_view_type_02

Main Features

Technical data

Blind assembly in the window
Function guaranteed up to 6 disassemblies
Installation load on clip support less than 150N with a thickness from 1.50 to 2.00 mm
Average assembly load in ABS (polypropylene) window 30N (-5 / +10)
Average disassembly load in ABS (polypropylene) window 75N (+/-15)

Characteristics

Material

Treatments

Clip

Steel XC68

Quenched and tempered

Grey Delta Protekt KL100

Other treatments avalaible on request

Dimensions

Data_Sheet_150093
[ units in inch ]
150092251_view_type_03

150 092 251

ICONES-prod-2
Claw Clip Butterfly®
ICONES-weight
0,9 grs
150092251_view_type_03

Main Features

Technical data

Blind assembly in the window
Impossible to disassemble
Installation load on clip support less than 150N with a thickness from 1.50 to 2.00 mm
Average assembly load in ABS (polypropylene) window 55N (+/-10)
Average disassembly load in ABS (polypropylene) window 245N (+/-10)

Characteristics

Material

Treatments

Clip

Steel XC68

Quenched and tempered

Grey Delta Protekt KL100

Other treatments avalaible on request

Dimensions

Data_Sheet_150090
[ units in inch ]
150090251_view_type_01

150 090 251

ICONES-prod-2
Claw Clip Butterfly®
ICONES-weight
0,9 grs
150090251_view_type_01

Main Features

Technical data

Blind assembly in the window
Function guaranteed up to 6 disassemblies
Installation load on clip support less than 150N with a thickness from 1.50 to 2.00 mm
Average assembly load in ABS (polypropylene) window 30N (-5 / +10)
Average disassembly load in ABS (polypropylene) window 75N (+/-15)

Characteristics

Material

Treatments

Clip

Steel XC68

Quenched and tempered

Grey Delta Protekt KL100

Other treatments avalaible on request

Dimensions

Data_Sheet_150090
[ units in inch ]
150080251_view_type_02

150 080 251

ICONES-prod-2
Clip Butterfly®
ICONES-weight
2,3 grs
150080251_view_type_02

Main Features

Technical data

Assembly of two parts one over the other
Possible panels thickness from 0.70 to 2.10 mm

Characteristics

Material

Treatments

Clip

Steel XC75

Quenched and tempered

Grey Delta Protekt KL100

Other treatments avalaible on request

Dimensions

Data_Sheet_150080
[ units in inch ]
150030251_view_type_01

150 030 251

ICONES-prod-2
Clip Butterfly®
ICONES-weight
1,0 grs
150030251_view_type_01

Main Features

Technical data

Blind assembly in the window
Function guaranteed up to 6 disassemblies
Installation load on clip support less than 20N with a thickness from 2.50 to 3.00 mm
Average assembly load in ABS (polypropylene) window 25N (+/-5)
Average disassembly load in ABS (polypropylene) window 100N (+/-15)

Characteristics

Material

Treatments

Clip

Steel XC68

Quenched and tempered

Grey Delta Protekt KL100

Other treatments avalaible on request

Dimensions

Data_Sheet_150030
[ units in inch ]

150 011 251

ICONES-prod-2
Claw Clip Butterfly®
ICONES-weight
1,3 grs
150010251_view_type_02

Main Features

Technical data

Blind assembly in the window
Function guaranteed up to 6 disassemblies
Installation load on clip support less than 20N with a thickness from 1.50 to 2.00 mm
Average assembly load in ABS (polypropylene) window 25N (-5 / +10)
Average disassembly load in ABS (polypropylene) window from 35N to 85N max

Characteristics

Material

Treatments

Clip

Steel XC68

Quenched and tempered

Grey Delta Protekt KL100

Other treatments avalaible on request

Dimensions

Data_Sheet_150011
[ units in inch ]
505151909_B-view type2

505 151 909

ICONES-prod-2
Rear triple stud fitting
ICONES-weight
225 grs
505151909_B-view type2

Features

ICONES-caracs

Characteristics

Fitting class                       Quick Change
Number of studs              3
Shear Plunger                 Yes
Fxz (rear) or Fz (front) > 75 kN

ICONES-aircrafts

Aircrafts

Airbus
Boeing
_ICONES-nocheck-vide

A320

_ICONES-nocheck-vide

A330

_ICONES-nocheck-vide

A350

_ICONES-nocheck-vide

A380

_ICONES-check

B737

_ICONES-check

B747

_ICONES-check

B767

_ICONES-nocheck-vide

B777

Components

Material

Treatment

Body

Stainless steel 17-4 Ph per ASTM A693

Zinc Nickel Type II Grade B per AMS 2417

Plunger

Stainless steel 17-4 Ph per ASTM A693

Zinc Nickel Type II Grade B per AMS 2417

Lever

Aluminum 7075-T651

Hard Anodization Type III Class 1 per MIL-A-8625

Dimensions

Data_Sheet_505151909
[ units in inch ]

Technical data

_ICONES-check
Safety indicator
_ICONES-check
Red
_ICONES-check
Green
_ICONES-check
Tool-less
_ICONES-check
Quick release
_ICONES-check
Positive engagement
_ICONES-check
Secured locking
_ICONES-check
Offset
_ICONES-nocheck-vide
Captive screw
505143909_F-view type

505 143 909

ICONES-prod-2
Front double stud fitting
ICONES-weight
123 grs
505143909_F-view type

Features

ICONES-caracs

Characteristics

Fitting class                       Torqued
Number of studs              2
Shear Plunger                 No
Fxz (rear) or Fz (front) > 50 kN

ICONES-aircrafts

Aircrafts

Airbus
Boeing
_ICONES-check

A320

_ICONES-check

A330

_ICONES-check

A350

_ICONES-nocheck-vide

A380

_ICONES-nocheck-vide

B737

_ICONES-nocheck-vide

B747

_ICONES-nocheck-vide

B767

_ICONES-nocheck-vide

B777

Components

Material

Treatment

Body

Stainless steel 17-4 Ph per ASTM A693

Zinc Nickel Type II Grade B per AMS 2417

Plunger

Aluminum 7075-T651

Hard Anodization Type III Class 1 per MIL-A-8625

Lever

Dimensions

Data_Sheet_505143909
[ units in inch ]

Technical data

_ICONES-nocheck-vide
Safety indicator
_ICONES-nocheck-vide
Red
_ICONES-nocheck-vide
Green
_ICONES-nocheck-vide
Tool-less
_ICONES-nocheck-vide
Quick release
_ICONES-nocheck-vide
Positive engagement
_ICONES-nocheck-vide
Secured locking
_ICONES-check
Offset
_ICONES-check
Captive screw
50T3R1004-ZN-view type

50T 3R1 004

ICONES-prod-2
Rear triple stud fitting
ICONES-weight
184 grs
50T3R1004-ZN-view type

Features

ICONES-caracs

Characteristics

Fitting class                      Torqued
Number of studs             3
Shear Plunger                 Yes
Fxz (rear) or Fz (front) > TBD

ICONES-aircrafts

Aircrafts

Airbus
Boeing
Tupolev
_ICONES-nocheck-vide

A320

_ICONES-nocheck-vide

A330

_ICONES-nocheck-vide

A350

_ICONES-nocheck-vide

B737

_ICONES-nocheck-vide

B747

_ICONES-nocheck-vide

B777

_ICONES-check

Other

Components

Material

Treatment

Body

Steel 42CrMo4 per EN 10293

Zinc Nickel Type II Grade B per AMS 2417

Plunger

Steel 42CrMo4 per EN 10293

Zinc Nickel Type II Grade B per AMS 2417

Lever

Dimensions

Data_Sheet_50T3R1004-ZN
[ units in inch ]

Technical data

_ICONES-check
Safety indicator
_ICONES-check
Red
_ICONES-nocheck-vide
Green
_ICONES-nocheck-vide
Tool-less
_ICONES-nocheck-vide
Quick release
_ICONES-nocheck-vide
Positive engagement
_ICONES-nocheck-vide
Secured locking
_ICONES-check
Offset
_ICONES-nocheck-vide
Captive screw
